ŞAFAK CNC BR3 (B25BR3 – B42BR3)
TECHNICAL SPECIFICATIONS
| B25BR3 | B42BR3 | ||
| Hydraulic Motor Power (kW) | 7,5 | 7,5 | |
| Max. Bending Diameter (mm) | Ø25×2 (Steel Tube) | Ø42×3 (Steel Tube) | |
| Max. Bending Radius (mm) | 140 | 220 | |
| Max. Bending Angle | 185° | 185° | |
| Max. Feeding Length (mm) | W/O mandrel | Infinite | Infinite |
| With mandrel | 3.000 | 3.550 | |
| Bending (°/sec) | 240° | 90° | |
| Axial Speeds | Progression (mm/sec) | 1.500 | 1.500 |
| Rotation (°/sec) | 600 | 600 | |
| Bending (°) | ±0,1 | ± 0,1 | |
| Precisions | Progression (mm) | ±0,1 | ±0,1 |
| Rotation (°) | ± 0,05 | ± 0,05 | |
| Dimensions | Width (mm) | 950 | 1.120 |
| Length (mm) | 4.650 | 6.647 | |
| Height (mm) | 1.400 | 1.560 | |
| Number of Programs | Infinite | Infinite | |
| Weight (Kg) | 2.000 | 4.500 | |
