ŞAFAK NC B65 / B80
PRODUCT SPECIFICATIONS
| NC B65 | NC B80 | ||
| Hydraulic Motor Power (kW) | 18,5 | 22 | |
| Max. Bending Diameter (mm) | Ø65×4 (Çelik Boru) | Ø80×4 (Çelik Boru) | |
| Max. Bending Radius (mm) | 250 | 250 | |
| Max. Bending Angle | 185° | 185° | |
| Max. Feeding Length (mm) | W/O mandrel | Infinite | Infinite |
| With mandrel | Optional1000 mm
(Standard) |
Optional1000 mm
(Standard) |
|
| Axial Speeds | Bending (°/sec) | 65° | 65° |
| Precisions | Bending (°) | ±0,1 | ±0,1 |
| Measurements * | Width (mm) | 1.250 | 1.300 |
| Length (mm) | 2.200 | 2.200 | |
| Height (mm) | 1.700 | 1.700 | |
| Number of Programs (Bosch &Rexroth) | 255 | 255 | |
| Number of Bending Programs | 5 | 5 | |
| Weight (Kg) | 3.600 | 4.250 | |
